Precision Needle Valve

Fuel injection systems, hydraulic valve banks, and chemical equipment use needle valves to control flow and shut off. If the needle tip does not match the seat, the valve will leak. Hayi Technology's precision needle valve has needle tip taper accuracy of ±0.01mm and seat roundness ≤0.005mm. Leakage after mating is ≤0.1ml/min. For example, a diesel injection system company had needle valves that leaked beyond the limit. We reground the needle tip and the seat, then lapped them together. After assembly, the injection pressure was stable and met the standard. This case shows needle valve precision decides system performance. Our MOQ is 1 piece.

Stainless Steel or Carbide Tip, Lapped to Seat

The needle material is often stainless steel (440C, 316L) or carbide (YG6). The taper can be 30°, 45°, or 60°. The seat is lapped together with the needle tip to achieve a linear seal. The valve body can have threaded or flanged connections. We hold ISO9001:2015 certification. Each needle valve gets an air tightness test at 0.5MPa with no bubbles. We can laser mark the specification and batch number. Before packing, we do 100% full inspection. We also accept third-party inspection. Our precision needle valve service is ready for your hydraulic and pneumatic clients.

Needle valves often need non-standard angles and sizes. Our custom sample time is 1 day minimum. Standard batch lead time is about 15 days. Payment: 50% deposit for custom development. Trade terms: EXW, FOB, DDP. During production, we send photo or video updates. If any problem occurs, we talk immediately and improve after we find the cause. We have a dedicated after-sales person. Hydraulic and pneumatic industries have strict leak requirements. Our technicians can help you choose the right tip angle and material. You can enter the precision fluid control field with our help.
