Vertical Milling Attachment

Many factories have horizontal milling machines or planer mills that can only cut horizontally. Hayi Technology's vertical milling attachment turns the spindle direction to vertical. You can machine both horizontal and vertical surfaces in one setup. For example, a pump body manufacturer needed to machine the side and top of a large pump casing. Previously they needed two setups. With the vertical attachment, they finished in one setup. Machining time was reduced by 40%. This case shows an attachment makes a machine more versatile. Our MOQ is 1 piece.

High Strength Cast Iron and Ground Bevel Gears

The housing is made of high strength cast iron. The internal bevel gears are made of 20CrMnTi steel. They are carburized and ground to DIN Grade 5 accuracy. Spindle taper options are BT40, BT50, and HSK. We can customize based on your machine interface. After assembly, we use a CMM to measure spindle axis perpendicularity (≤0.01mm per 100mm). We hold ISO9001:2015 certification. Each attachment runs at no load for 30 minutes before shipping. Temperature rise is ≤15°C. Our vertical milling attachment costs only about 15% of a new vertical-horizontal 5-axis machine.

A new vertical-horizontal 5-axis machine costs a lot. Adding a vertical attachment costs just 15% of that. Our custom development time is 1 day for a technical proposal. Production lead time is about 15 days. Payment: 50% deposit. Trade terms: EXW, FOB, DDP. We offer a one-year warranty. If any problem occurs, we talk immediately and improve after we find the cause. We have a dedicated after-sales person. You can sell this to factories that machine large box-type parts like transmission housings and pump bodies. Our technicians can help you confirm the connection method. You can help your clients improve machine utilization.
