CNC Milling Robot

Automotive parts and appliance housings have flash from molding. Manual grinding is slow and uneven. Hayi Technology's cnc milling robot system combines a 6-axis robot arm with a high speed spindle. It automatically does deburring, trimming, and drilling. For example, a car trim factory had 2,000 bumpers to trim every day. We installed one robot system. It ran 24 hours a day. The defect rate dropped from 5% to 0.5%. The client said the system paid for itself in one year. This case shows automation is the trend. We supply a minimum of 1 system.

High Speed Spindle and Constant Force Floating Mechanism

We use a 6-axis industrial robot with a payload of ≥20kg and repeat positioning accuracy of ±0.05mm. The high speed electric spindle runs at 24,000 rpm with power of 3-7.5 kW. We add a constant force floating mechanism to adapt to raw part tolerances. We provide a complete control cabinet and offline programming software. All components meet CE standards. We hold ISO9001:2015 certification. Our technicians can do path programming and debugging based on your part drawing. The cnc milling robot system can switch products in about 10 minutes by changing the program.

A traditional special machine takes hours to change over. A robot takes just 10 minutes to load a new program. Our project cycle is about 15 days for system integration. Payment: 50% deposit. Trade terms: EXW, FOB, DDP. We provide pre-sale feasibility analysis and post-sale on-site training. If any system problem occurs, we talk immediately and improve after we find the cause. We have a dedicated after-sales person. Many factories want to start automation but do not know how. Our technicians can help you evaluate the part and cycle time. You can offer a turnkey solution to your clients.
