Rotary Milling Vise

Jobs like drilling angled holes, milling curved surfaces, and indexing around a circle normally need a 4-axis machine. Hayi Technology's rotary milling vise has a precision worm gear indexing plate built in. Mount it on a 3-axis mill and you can do indexed machining. For example, a valve factory needed to drill three holes at different angles on a valve body. We used a rotary vise. The job was done without changing fixtures. The client said they saved the cost of a 4-axis machine. This case shows a small fixture solves a big problem. Our MOQ is 1 piece.

Ductile Iron Body and Precision Worm Gear

The vise body is made of high strength ductile iron QT600-3 or high quality 45# steel. It is age-relieved to remove internal stress. The jaws are Cr12MoV mold steel hardened to HRC58-62. The indexing mechanism uses a precision worm and worm gear with a self-lock feature. It comes with a graduated scale or digital readout. We hold ISO9001:2015 certification. Before shipping, we check jaw parallelism (≤0.01mm per 100mm) and indexing accuracy (±30 arc seconds). We can custom make jaw width and opening range. Our rotary milling vise costs only about 30% of a 4-axis rotary table.

A 4-axis rotary table is expensive. A rotary vise costs just 30% of that. Our standard models are in stock and ship in 1 day. Custom models take about 15 days. Payment: 30% deposit. Trade terms: EXW, FOB. If any problem occurs, we talk immediately and improve after we find the cause. We have a dedicated after-sales person. Small mold shops and part machining shops do not have 4-axis machines but often need angled machining. Our technicians can help you confirm if the indexing accuracy meets your needs. You can help your clients upgrade their capabilities at low cost.
