Right Angle Milling Head Attachment

Large molds and wind turbine gearbox housings have deep cavities that standard milling heads cannot reach. Hayi Technology's right angle milling head attachment (90° angle head) turns the spindle direction by 90 degrees. It enables side milling and machining inside deep cavities. For example, a wind turbine parts factory needed to machine the inside wall of a 2-meter deep gearbox housing. We used an extended length right angle head to reach inside. The job was done in one setup. The client said they previously had to disassemble the part. This case shows a right angle head solves space problems. Our MOQ is 1 piece.

Heavy Duty Design with Double Row Bearings

Our right angle heads are designed for heavy cutting. They use double row angular contact bearings or tapered roller bearings to handle large radial and axial forces. Gears are carburized and ground. The output end uses a standard ER or heavy duty milling chuck. Speed range is 1000-3000 rpm. We can provide extended length versions for deep cavities and light high speed versions for finishing. We hold ISO9001:2015 certification. Each head gets a static accuracy inspection and a load test before shipping. Our right angle milling head attachment lets you machine multiple surfaces in one setup.

A part that needed three setups before can be done in one setup with a right angle head. This avoids repeated positioning errors. Our standard models are in stock and ship in 1 day. Custom models take about 15 days. Payment: 50% deposit. Trade terms: EXW, FOB. If any problem occurs, we talk immediately and improve after we find the cause. We have a dedicated after-sales person. Mold shops and heavy machinery companies often need to machine deep cavities. Our technicians can help you choose the right type (standard or extended length). You can solve special machining problems for your clients.
