Robotic Welding Fixtures

Automotive parts, sheet metal, and pipe welding done by hand can lead to missed or uneven welds due to fatigue. Hayi Technology's robotic welding fixtures system includes a welding robot, a positioner, and locating fixtures. For example, a motorcycle frame maker had five welders making 200 frames per day. We installed two welding robots. They made 400 frames per day with consistent weld beads. The client said the welding defect rate dropped from 3% to 0.5%. This case shows robot welding is stable and efficient. We supply a minimum of 1 set.

Positioners and Pneumatic Clamps Ensure Accurate Part Location

We use arc welding dedicated 6-axis robots with digital welders. They support CO₂, TIG, and MIG/MAG. The positioner is servo-driven and moves in sync with the robot. This keeps the weld seam in the best position at all times. Fixtures use pneumatic clamps with repeat positioning accuracy of ±0.1mm. We hold ISO9001:2015 certification. We can add a torch collision sensor and optional seam tracking. Our technicians can help you design the welding fixtures. Our robotic welding fixtures system allows fast changeover. When the product changes, just change the fixture module.

When the product changes, just change the fixture module. Our system integration lead time is about 15 days. Payment: 50% deposit. Trade terms: EXW, FOB, DDP. We provide operator training. If any system problem occurs, we talk immediately and improve after we find the cause. We have a dedicated after-sales person. Sheet metal, automotive, and hardware industries have high welding volumes and need consistent quality. Our technicians can help you verify the welding process for your parts. You can help your clients improve welding quality and output.
