Brass CNC Turned Parts
Brass is Easy to Machine, But Fine Details are Hard
Pneumatic fittings, hydraulic pipe connectors, and electrical terminals need accurate threads, a bright surface, and no burrs. Hayi Technology's brass cnc turned parts service uses high precision automatic lathes or CNC turning centers. Outside diameter range is from 2mm to 800mm. Length can go up to 2000mm. For example, an instrument company needed a batch of brass valve cores with thread accuracy of 6H. We used thread rolling instead of thread turning. The strength was higher and the pass rate was 100%. The client said they never needed to clean burrs again. This case shows details decide efficiency. Our MOQ is 1 piece.
|
Parameter |
Details |
|
Minimum Order Qty |
1 piece |
|
Sample Time |
1 day minimum |
|
Standard Lead Time |
~15 days |
|
Outside Diameter Range |
2mm to 800mm |
|
Length Range |
Up to 2000mm |
|
Tolerance Capability |
±0.01mm |
|
Common Brass Grades |
C36000 (free cutting), C37700, CW614N (RoHS compliant) |
|
Finish Options |
Ultrasonic cleaning, deburring, passivation, nickel or chrome plating |
|
Certification |
ISO9001:2015 (Cert No. 19925Q02204R0S) |
Eco-Friendly Brass and Automatic Feeders
We use brass grades like C36000 (free cutting), C37700, and CW614N. Lead content meets RoHS standards. We can also provide lead-free brass. Our machines have automatic bar feeders for 24/7 continuous production. Tolerance capability is ±0.01mm. Post processing includes ultrasonic cleaning, deburring, passivation, and plating (nickel or chrome). We hold ISO9001:2015 certification. Each batch is checked with thread gauges and sampled for dimensions. Before packing, we do 100% full inspection. We also accept third-party inspection. Our brass cnc turned parts are perfect for high volume orders with low per piece cost.
Low Cost, High Volume, and Discounts for Large Orders
Brass turned parts are good for mass production. The single piece cost is very low. Our custom sample time is 1 day minimum. Standard order lead time is about 15 days. Payment: 30% deposit for standard products, 50% deposit for custom products, balance before shipment. We support EXW, FOB, and DDP. Large orders get a discount. During production, we send photo or video updates. If any problem occurs, we talk immediately and improve after we find the cause. We have a dedicated after-sales person. The pneumatic and hydraulic industries need large quantities of brass fittings. Our technicians can help you optimize thread parameters. You can secure a long term consumable parts client with our help.
Hot Tags: brass CNC turned parts, China brass CNC turned parts manufacturers
